WP500B
WELPING
360500
Availability: | |
---|---|
Quantity: | |
HDPE pipes have been used extensively in the range of piping applications in the municipal, industrial, marine, mining, landfill, duct and agricultural industries.
Butt fusion welding is an effective, trouble free connecting method for PE, HDPE pipes. In pressurized piping applications, butt fusion welding can provide reliable pipe joints, strong enough just like a whole pipe.
To achieve a good jointing, a steady, precise, robust butt welding machine is critical. WELPING had been developing, manufacturing and distributing HDPE butt welding equipment since 2005. it's our pleasure to help you build reputation in the piping project.
The Hydraulic butt fusion welding machine, mainly consists of 3 major parts: Carriage (also called frame or base), planing tool (also called trimmer or facer) and heater, hydraulic station with control device. Carriage for precise face joint and steady pipe clamping, planing tool and heater responsible for accurate trimming and heating, hydraulic station provides actuation and control.
1. Robust structure of carriage part with streamline outlook
2. Durable copper wiring motor, HSS blade, PTFE coating from Dupont or Daikin
3. Hydraulic station with built-in digital control system
4. Full gear transmission in planing tool, instead of chain, more heavy duty
5. Data logging device optional
Data Sheet
Model | WP500B |
Welding range (mm) | 250-500 |
Standard reducers (mm) | 250-280-315-355-400-450-500 |
Power supply | 380V/50Hz, 3PH |
Total power | 9.1 KW |
Heating plate | 6.5 KW |
Planing tool | 1.1 KW |
Hydraulic station | 1.5 KW |
Pressure adjusting range | 0-16 MPa |
Max Temperature of heating plate | 270ºC |
Temperature Deviation | ±7ºC |
